Collimated Beam & Uniformity
Uncollimated LED curing lights deliver significantly less curing energy per depth of cure. As shown in Fig 1, the power of an uncollimated curing light quickly diminishes, offering very little curing energy for larger restorations.
The collimated beam of the Radii-Cal CX delivers curing uniformity across all curing depths. This ensures a fast and predictable cure for all restorations.
Durable long life battery
The Radii-Cal CX does not require frequent recharging between patients. When fully charged, the Radii-Cal CX provides 1,200 x 10 second cures.
Sensitivity Protection Ramp
During the first 5 seconds, the Radii-Cal CX light output power gradually increases. This ‘soft-start’ polymerization minimises stress at the restoration-enamel/dentine junction and reduces marginal gaps in the restoration. ˆThis ensures longer integrity of your restoration and decreases post-op sensitivity.
Built In Radiometer
The Radii-Cal CX has a built-in radiometer to check the functionality of the unit. This radiometer is callibrated to the Radii-Cal CX power and collimated lens.
Optimal Wavelength Spectrum
The Radii-Cal CX LED targets the key 440-480nm wavelength, [fig 2] which maximises the activation of camphorquione monomers. This ensures efficient curing of light cured restoratives.
Technical data
| Handpiece (battery, control section and standard LED attachment) |
| Wavelength range: |
440 nm – 480 nm |
| Peak wavelength range: |
460 nm |
| Ramp to full intensity: |
5 seconds |
| Light intensity: |
1200 mW/cm2Â (peak) |
| Duration of continuous use |
20 seconds |
| Total continuous run time with fully charged battery: |
3 hours, 20 minutes |
| Dimensions: |
22 mm diameter x 243 mm long |
| Weight: |
144 g / 5.1 ounces |
| Battery: |
Li-ion 7.4V/14 wh |
| Plug Pack |
| AC input: |
100-240V ~ 0.8A, 50/60 Hz |
| DC Output: |
12V 1.66A, 20.0W MAX |
| Dimensions: |
34 mm (W) x 41 mm (H) x 62.5 mm (L) |
| Weight: |
104 g / 3.6 ounces |
| Charger |
| Time to charge battery: |
60 – 180 minutes |
| Operating temperature: |
10°C – 40°C |
| Total height with handpiece inserted |
255 mm |
| Dimensions: |
70 mm (W) x 40 mm (H) x 130 mm (L) |
| Weight |
84 g / 3 ounces |
